Biological Microscope BM2000

Excellent image quality with infinite optical system.

Comfortable operating with perfect streamlined structure design.

Better illumination with sliding-in centerable condenser, convenient replacement with phase contrast and dark field condenser.

Technical Specifications


Optical System	Infinite Optical System
Viewing Head	Seidentopf Binocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm
Viewing Head	Seidentopf Trinocular Viewing Head, Inclined at 30°, 360° Rotatable, Interpupillary 48-75mm
Eyepiece	WF10X/20
Eyepiece	WF15X/16
Objective	Infinite plan Achromatic Objective 4X, 10X, 40X, 100X
Objective	Infinite plan Achromatic Objective 20X, 60X
Nosepiece	Backward Quadruple Nosepiece
Nosepiece	Backward Quintuple Nosepiece
Focusing System	Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 22mm
Stage	Rectangular 230X150mm, Cross Travel 78X54mm, Using Low-positioned X/Y Coaxial Control Knob
Condenser	Abbe Condenser NA1.25 with Aperture Diaphragm
Illumination	12V/20W Halogen Lamp, Brightness Adjustable
Illumination	S-LED Illumination, Brightness Adjustable
Optional	Photo Attachment, Video Attachment, Polarization Set, Kohler Illumination, Phase Contrast Kit
