Optical System

　Infinite Optical System

　Viewing Head

　Seidentopf Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary 48-75mm

　Eyepiece

　Wide Field Eyepiece WF10X/20, Eyepiece Tube Diameter 30mm

　Wide Field Eyepiece WF15X/16

　Wide Field Eyepiece WF20X/12

　Objective

　LWD Infinite Plan Achromatic Objective 4X/0.10 WD=22

　LWD Infinite Plan Achromatic Phase Objective

　10X/0.25  WD=6

　20X/0.4   WD=3.1

　40X/0.55  WD=2.2

　High-level Phase Contrast Objective

　10X/0.25  WD=6

　20X/0.4   WD=3.1

　40X/0.55  WD=2.2

　Nosepiece

　Backward Quintuple Nosepiece

　Condenser

　ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm)

　Centering Telescope

　Centering Telescope(Φ30mm)

　Phase Annulus

　10X、20X、40X Phase Annulus Plate(Adjustable)

　Stage

　Plain Stage 230X170mm

　Glasse Insert

　Attachable Mechanical Stage,X、Y Coaxial Control,Moving Rang 80X120mm

　Auxiliary Stage

　Terasaki Holder

　Petri Dish HolderΦ38

　Petri Dish HolderΦ54

　Focusing System

　Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm down 4.5mm

　Illumination

　6V30W Halogen Lamp, Brightness Adjustable

　Filter

　Blue、Green and Ground Glass, Diameter 45mm

　Accessories

　Photo Attachment

　C Mount 0.4X

　Epi-Fluorescent Attachment

　Modulation Contrast
